Electronic brake assembly for a bicycle


Patent Number: US8899384B2

An electronic brake device for use with a wheel of a bicycle provides, among other features, wireless, remote disengagement of a wheel brake. A brake coupled to a housing is movable between an engaged position and a disengaged position. The housing includes a receiver configured to receive a command signal, and a processor operative to identify the received command signal. If the command signal is identified as a first command signal, the processor outputs a first control signal. An electric motor is operatively coupled to the brake to selectively move the brake from the engaged position in which the wheel of the bicycle is being braked to the disengaged position in which the wheel of the bicycle is free of any brake contact in response to the first control signal. Measured movement of the brakes between fully braked or fully disengaged positions are possible in the disclosed arrangement.
